Molten Metal Splashes Impact Test Apparatus EN 348 and ISO 9150

Detail produk:

Tempat asal:	CINA
Nama merek:	AI
Sertifikasi:	ISO
Nomor model:	MMS

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1 set
Harga:	Bisa dinegosiasikan
Kemasan rincian:	Kasus Kayu Lapis
Waktu pengiriman:	60 hari
Syarat-syarat pembayaran:	Western Union, T/T, L/C
Menyediakan kemampuan:	20 set per bulan

Hubungi sekarang

Detil Deskripsi produk

Standar uji:	EN 348 dan ISO 9150	Pasokan Gas:	Oksigen dan asetilena
Berat:	42kg	Jaminan:	1 tahun
Ukuran:	500mm(L)X 700mm(Tinggi)X 500mm(D)	Catu Daya:	230VAC 50Hz, 10A

Molten Metal Splashes Impact Test Apparatus

Name: Molten Metal Splashes Impact Test Apparatus EN 348 and ISO 9150
Brand: Advanced Instruments Co.,Ltd
SKU: MMS
Availability: InStock

INTRODUCTION

Projections of molten metal drops at a point on a vertical oriented test specimen and measurement of the number of the drops required to cause a 40 K temperature rise in a sensor behind the specimen.

FEATURE

Drop guide to collect the drops and to guide them towards the vertically oriented test specimen.
Senor for measuring the temperature linked to a recording device.
Holding frame and counterweights for the test specimen.
Motor speed can be adjust so that the steel rod is fed at the rate of (10 f 1) g/mm.
Needle valves adjust the O2 and acetylene flow rate.
LCD Screen display and control the motor speed.

Installation requirements

Electrical	230 volts Nominal 10 Amps
Ambient Temperature	Operating25±5℃
Gas supplies	Oxygen and acetylene
Dimensions	500mm(W)X 700mm(H)X 500mm(D)
Weight	42KG
Applicable standards	EN 348 and ISO 9150
