Protective Clothing Vertical Flame Spread Tester ISO 6941,ISO 15025,95/28/EC

Detail produk:

Tempat asal:	CINA
Nama merek:	AI
Sertifikasi:	ISO
Nomor model:	VFT

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1 set
Harga:	Bisa dinegosiasikan
Kemasan rincian:	Kasus Kayu Lapis
Waktu pengiriman:	60 hari
Syarat-syarat pembayaran:	Western Union, T/T, L/C
Menyediakan kemampuan:	20 set per bulan

Hubungi sekarang

Detil Deskripsi produk

Standar uji:	ISO 6941,ISO 15025,95/28/EC	Ukuran:	410mm(L) X 900mm(T) X 380mm(T)
Berat:	36kg	Jaminan:	1 tahun
Pasokan Gas:	Propana dan Udara Terkompresi	Catu Daya:	230 Volt AC 50Hz

Protective Clothing Vertical Flame Spread Tester

Name: Protective Clothing Vertical Flame Spread Tester ISO 6941,ISO 15025,95/28/EC
Brand: Advanced Instruments Co.,Ltd
SKU: VFT
Availability: InStock

INTRODUCTION

Vertical Flame Tester is suitable for the measurement of limited flame spread properties of Protective clothing.. A defined flame from a specified burner is applied for 10 s to the surface or the bottom edge of textile specimens which are vertically oriented.

FEATURE

The vertical flame test apparatus is designed and manufactured according to ISO 15025 standards.
The flame spread tester can be updated to meet the requirement of ISO6941,ISO 6940 etc by using different specimen holders.
The apparatus consists of mounting frame, gas burner, test specimen holder with Supporting pins.
The angle of the burner can be pre-setted and adjusted automatically.
Flame application time can be pre-setted and operate automatically.
Afterflame time and afterglow time recorded by LCD screen.

Installation requirements

Electrical	230 Volts AC 50Hz.
Ambient Temperature	Operating 25±5℃
Dimensions	4410mm(W) X 900mm(H) X 380mm(D)
Weight	36KG
Applicable standards	ASTM D2863,ISO 4589-2,NES 714
Gas	Propane and air compressed air
