80kV Electrical Transformer Insulation Oil Breakdown Voltage BDV Tester

80kV Electrical Transformer Insulation Oil Breakdown Voltage BDV Tester

    • 80kV Electrical Transformer Insulation Oil Breakdown Voltage BDV Tester
    • 80kV Electrical Transformer Insulation Oil Breakdown Voltage BDV Tester
    • 80kV Electrical Transformer Insulation Oil Breakdown Voltage BDV Tester
    • 80kV Electrical Transformer Insulation Oil Breakdown Voltage BDV Tester

    Detail produk:

    Tempat asal: CINA
    Nama merek: AI
    Sertifikasi: ISO
    Nomor model: BDV

    Syarat-syarat pembayaran & pengiriman:

    Kuantitas min Order: 1 set
    Harga: Bisa dinegosiasikan
    Kemasan rincian: Karton
    Waktu pengiriman: 15 hari
    Syarat-syarat pembayaran: T/T, Western Union, L/C
    Menyediakan kemampuan: 100000 set per bulan
    Hubungi sekarang
    Detil Deskripsi produk
    Catu Daya: AC220V, 50Hz Menampilkan: LCD
    Tegangan output: AC 0V~80KV atau 0~100KV Ketepatan: ±(1% skala penuh + 2 digit)
    Jaminan: 1 tahun kata kunci: Penguji Minyak Isolasi, Penguji BDV Tegangan Rusak



    IEC156 80kV Transformer Oil Breakdown Voltage BDV Tester

    80kV Electrical Transformer Insulation Oil Breakdown Voltage BDV Tester



    I.Introduction:

    • It is designed according to IEC156 Insulating Oil Dielectric Strength Test Method;

    • The oil test vessel with temperature measurement unit, so it can detect oil temperature.

    • With 8 Kinds of test mode as optional: IEC156, IS6792, BS5874, ASTM D1816 , ASTM D877, Proof test, 5 minutes standard test, Manual test;

    • This transformer oil breakdown voltage tester has large LCD display, all the selection can be done by touch panel with color LCD;

    • This insulation oil BDV testesr also has micro-printer and can store 100 groups data, test data can also be unload to PC and output word report automatically;

    • This transformer oil withstand voltage tester is multi-functional, stable, and easy for operation



    II.Specifications:

    No. Parameters Specifications
    1 Output voltage AC 0V~80KV or 0~100KV
    2 Rate of voltage rise 0.5kv/s± 5%, 2kv/s± 5%, 3kv/s± 5%, 5kv/s± 5%
    3 Max. test times 9
    4 Stir time 0~999s
    5 Wait time 0~999s
    6 Measurement accuracy ±(1% of full scale + 2 digits)
    7 Resolution 0.1KV
    8 Temperature measurement range 0°C to 70°C, or better
    9 Temperature resolution 1°C, or better
    10 Data storage 100 groups
    11 Weight 38kg
    12 Size 550 mm*500mm*580mm
    13 Power supply AC220V, 50Hz
    14 Working environment Room temperature to 45°C, humidity<85%




    Picture of Automatic Insulation Oil BDV Tester Spares

    80kV Electrical Transformer Insulation Oil Breakdown Voltage BDV Tester
