80kV Power Transformer Insulation Oil Breakdown Voltage BDV Tester

80kV Power Transformer Insulation Oil Breakdown Voltage BDV Tester

80kV Power Transformer Insulation Oil Breakdown Voltage BDV Tester

Detail produk:

Tempat asal: CINA
Nama merek: AI
Sertifikasi: ISO
Nomor model: BDV

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order: 1 set
Harga: Bisa dinegosiasikan
Kemasan rincian: Karton
Waktu pengiriman: 15 hari
Syarat-syarat pembayaran: Western Union, T/T, L/C
Menyediakan kemampuan: 100000 set per bulan
Hubungi sekarang
Detil Deskripsi produk
Catu Daya: AC220V, 50Hz Menampilkan: LCD
Tegangan output: AC 0V~80KV atau 0~100KV Ketepatan: ±(1% skala penuh + 2 digit)
Jaminan: 1 tahun kata kunci: Penguji Minyak Isolasi, Penguji BDV Tegangan Rusak

IEC156 80kV Transformer Oil Breakdown Voltage BDV Tester





I.Introduction:

BDV-2 Transformer oil tester is developed according to DL/T846.7-2004 "Insulating oil dielectric tester" standard and the IEC/ASTM international standard. Built-in EEPROM memory can save 100 sets of test data, and test results can be printed at any time. It has the advantages of simple operation, powerful function, stable and reliable, and high degree of automation



II.Specifications:

No. Parameters Specifications
1 Output voltage AC 0V~80KV or 0~100KV
2 Rate of voltage rise 0.5kv/s± 5%, 2kv/s± 5%, 3kv/s± 5%, 5kv/s± 5%
3 Max. test times 9
4 Stir time 0~999s
5 Wait time 0~999s
6 Measurement accuracy ±(1% of full scale + 2 digits)
7 Resolution 0.1KV
8 Temperature measurement range 0°C to 70°C, or better
9 Temperature resolution 1°C, or better
10 Data storage 100 groups
11 Weight 38kg
12 Size 550 mm*500mm*580mm
13 Power supply AC220V, 50Hz
14 Working environment Room temperature to 45°C, humidity<85%
