Name: Loop resistance tester Contact resistance tester 100A 200A 400A 600A
Brand: Advanced Instruments Co.,Ltd
SKU: CRT
Availability: InStock

Rumah Produk Alat Uji Kelistrikan

Loop resistance tester Contact resistance tester 100A 200A 400A 600A

Detail produk:

Tempat asal:	CINA
Nama merek:	AI
Sertifikasi:	ISO
Nomor model:	CRT

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1 set
Harga:	Bisa dinegosiasikan
Kemasan rincian:	Kasus Kayu Lapis
Waktu pengiriman:	15 hari
Syarat-syarat pembayaran:	Western Union, T/T, L/C
Menyediakan kemampuan:	100000 set per bulan

Hubungi sekarang

Detil Deskripsi produk

Catu Daya:	AC220V±10%, 50Hz/60Hz	Menampilkan:	LCD
Rentang pengukuran:	0-1999,9 μΩ	Mengukur Arus:	DC 100A, 200A, 400A, 600A
Jaminan:	1 tahun	kata kunci:	Instrumen Resistensi Loop, Penguji Resistensi Kontak

100A 200A 400A 600A Low Contact Loop Resistance Tester

Introduction:

This Low Contact Loop Resistance Tester is used to test the contact resistance of circuit breaker or high current cable contacts. It is designed according to IEC62271. The main application of the tester is the measurement of circuit breaker contact resistance.

Features:

★ Contact resistance measurement

★ Result print

★ Unload data to PC

Specifications:

1.Measurement range: 0-1999.9 μΩ

Resolution:0.1 μΩ

2.Test current: DC 200A/100A for different selection

4. Maximum error< 0.5 %RDG+0.05%FS

5.Display mode: LCD

6. Save no more than 100 groups of data

7. RS232 computer interface
