AIC2571 Digital Ground Resistance Tester Ground Resistance Meter

Detail produk:

Tempat asal:	CINA
Nama merek:	AI
Sertifikasi:	ISO
Nomor model:	AIC2571

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1 buah
Harga:	Bisa dinegosiasikan
Kemasan rincian:	Karton
Waktu pengiriman:	15 hari
Syarat-syarat pembayaran:	Western Union, T/T, L/C
Menyediakan kemampuan:	100000 set per bulan

Hubungi sekarang

Detil Deskripsi produk

Rentang pengukuran:	0-1.999Ω, 2-19.99Ω ,20-199.9Ω	Menampilkan:	Digital
kata kunci:	Penguji Ketahanan Pembumian, Pengukur Ketahanan Pembumian	Berat:	2kg
Warna:	Putih	Jaminan:	1 tahun

AIC2571 Digital Ground Resistance Tester

Name: AIC2571 Digital Ground Resistance Tester Ground Resistance Meter
Brand: Advanced Instruments Co.,Ltd
SKU: AIC2571
Availability: InStock

1 Application

This earthing resistance tester is suitable to test earth resistance of all kinds of devices and Conductor resistance of low resistance in electric power, post,oil,chemistry,communication,mine industry and so on..It also can test resistance rate of soil and voltage to earth.

2 Technical parameters

Range	Constant Current Value	Precision and Error		Resolution	Additional
0-1.999Ω 2-19.99Ω 20-199.9Ω AC:0-19.99V	10mA(2Ω) 10mA(20Ω) 1mA(200Ω) <±(10%+1d)	0-0.2Ω<±(3%+1d) 0.2-199.9Ω <±(1.5%+1d) 1-20V<±(3%+1d)		0.001Ω 0.01Ω 0.1Ω 0.01V	Rc:2Ω 20Ω/<1KΩ 200Ω/<10KΩ Rp:<50KΩ Error:< ±5%
Power Consumption	Earth Voltage	Humidity	≤85%RH	Power Supply	Weight: <1.8Kg
≤2W	<5V,<±5%	Temperature	0℃-40℃	7.2-9V DC or 220V AC	Size: 200×200×110mm3

AIC2571 Digital Ground Resistance Tester Ground Resistance Meter
