Molten Metal Splash Impact Tester EN 348 And ISO 9150

Molten Metal Splash Impact Tester EN 348 And ISO 9150

    • Molten Metal Splash Impact Tester EN 348 And ISO 9150
    • Molten Metal Splash Impact Tester EN 348 And ISO 9150
    • Molten Metal Splash Impact Tester EN 348 And ISO 9150
    • Molten Metal Splash Impact Tester EN 348 And ISO 9150
    • Molten Metal Splash Impact Tester EN 348 And ISO 9150
    • Molten Metal Splash Impact Tester EN 348 And ISO 9150

    Detail produk:

    Tempat asal: CINA
    Nama merek: AI
    Sertifikasi: ISO
    Nomor model: MMS

    Syarat-syarat pembayaran & pengiriman:

    Kuantitas min Order: 1 set
    Harga: Bisa dinegosiasikan
    Kemasan rincian: Kasus Kayu Lapis
    Waktu pengiriman: 60 hari
    Syarat-syarat pembayaran: Western Union, T/T, L/C
    Hubungi sekarang
    Detil Deskripsi produk
    Standar uji: EN 348 dan ISO 9150 Pasokan Gas: Oksigen dan asetilena
    Berat: 42kg Jaminan: 1 tahun
    Ukuran: 500mm(L)X 700mm(Tinggi)X 500mm(D) Catu Daya: 230VAC 50Hz, 10A

    Molten Metal Splash Impact Tester

    INTRODUCTION

    Projections of molten metal drops at a point on a vertical oriented test specimen and measurement of the number of the drops required to cause a 40 K temperature rise in a sensor behind the specimen.​



    FEATURE

    • Drop guide to collect the drops and to guide them towards the vertically oriented test specimen.

    • ​Senor for measuring the temperature linked to a recording device.

    • ​Holding frame and counterweights for the test specimen.

    • ​Motor speed can be adjust so that the steel rod is fed at the rate of (10 f 1) g/mm.

    • Needle valves adjust the O2 and acetylene flow rate.

    • ​LCD Screen display and control the motor speed.

    Installation requirements

    Electrical 230 volts Nominal 10 Amps
    Ambient Temperature Operating25±5℃
    Gas supplies Oxygen and acetylene
    Dimensions 500mm(W)X 700mm(H)X 500mm(D)
    Weight 42KG
    Applicable standards EN 348 and ISO 9150



    Photos of Molten Metal Splashes Impact Tester

    Molten Metal Splash Impact Tester EN 348 And ISO 9150
