Name: ASTM D1831 Roll Stability Tester for Lubricating Grease Testing
Brand: Advanced Instruments Co.,Ltd
SKU: AIC-1831
Availability: InStock

Rumah Produk Analisis Minyak Pelumas dan Gemuk Pelumas

ASTM D1831 Roll Stability Tester for Lubricating Grease Testing

Detail produk:

Tempat asal:	CINA
Nama merek:	AI
Sertifikasi:	ISO
Nomor model:	AIC-1831

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1 Atur ASTM D1831 Roll Stability Tester
Harga:	Bisa dinegosiasikan
Kemasan rincian:	Astm D1831 Roll Stability Tester dikemas dalam case kayu lapis
Waktu pengiriman:	20 hari
Syarat-syarat pembayaran:	Western Union, T/T, L/C
Menyediakan kemampuan:	20 set per bulan

Hubungi sekarang

Detil Deskripsi produk

Standar uji:	ASTM D1831, SH/T0122	Mode Pemanasan:	Cincin listrik
Modus pengaturan waktu:	Pengatur waktu digital	Kecepatan motorik:	155 ~ 180rpm
Catu Daya:	AC220V 50Hz	Jaminan:	1 tahun
Warna:	Putih	Kekuatan total:	1000W
Kisaran Pengontrolan Suhu:	21 ℃ ~ 38 ℃

AIC-1831 Roll Stability Tester

Introduction

Using a certain amount of sample, at room temperature, after working on a roller testing machine for 2 hours, determine the working penetration of the grease before and after the test.This Roll Stability Tester is suitable for measuring the consistency change of the grease after working on the roller testing machine to judge the mechanical shear stability of the grease.

I. Main Features

◆Stainless steel roller: Φ90×180mm 5kg;

◆The idler wheel has a positioning ring to control the normal operation of the roller;

◆A drive motor is installed below to keep the speed at 155～180r/min;

◆Belt drive roller;

◆Microcomputer thermostat, digital display, accuracy ±5℃ PT100 sensor;

◆Digital timer, recording working time, with wind alarm;

◆Two rollers can be tested at the same time;

◆There is a thermometer hole on the cover of the instrument box for temperature correction.

II.Technical Specifications

1	Applicable standards	ASTM D1831,SH/T0122
2	Heating mode	Electric ring
3	Timing mode	Digital timer
4	Temperature controlling range	21℃~38℃
5	Motor speed	155~180RPM
6	Working units	2 units
7	Power supply	AC 220V ,50Hz
8	Total power	1000W

III.Accessories List

No.	Name	Quantity
1	Roll Stability Tester	1 Set
2	Roller	2 Sets
3	Wrench	2 PCS
4	Thermometer (0~100℃)	1 PC
5	Fuse (20A)	4 PCS
6	Sample dish	15 PCS
7	Scraper	1 PC
8	Manual book	1 Copy

ASTM D1831 Roll Stability Tester for Lubricating Grease Testing
