IEC 156 Dielectric Breakdown Voltage Portable Oil Tester

Hubungi sekarang

Detil Deskripsi produk

Tegangan output:	AC 0V~80KV atau 0~100KV	Ketepatan:	±(1% skala penuh + 2 digit)
Menampilkan:	LCD	Catu Daya:	AC220V, 50Hz
kata kunci:	Set Pengujian Oli, Penguji Tegangan Kerusakan	Jaminan:	1 tahun

Dielectric Breakdown Voltage Portable Oil Tester

I.Introduction:

It is designed according to IEC156 Insulating Oil Dielectric Strength Test Method;
The oil test vessel with temperature measurement unit, so it can detect oil temperature.
With 8 Kinds of test mode as optional: IEC156, IS6792, BS5874, ASTM D1816 , ASTM D877, Proof test, 5 minutes standard test, Manual test;
This dielectric oil breakdown voltage tester has large LCD display, all the selection can be done by touch panel with color LCD;
This dielectric breakdown voltage testing set also has micro-printer and can store 100 groups data, test data can also be unload to PC and output word report automatically;
This portable oil testing set is multi-functional, stable, and easy for operation

II.Specifications:

No.	Parameters	Specifications
1	Output voltage	AC 0V~80KV or 0~100KV
2	Rate of voltage rise	0.5kv/s± 5%, 2kv/s± 5%, 3kv/s± 5%, 5kv/s± 5%
3	Max. test times	9
4	Stir time	0~999s
5	Wait time	0~999s
6	Measurement accuracy	±(1% of full scale + 2 digits)
7	Resolution	0.1KV
8	Temperature measurement range	0°C to 70°C, or better
9	Temperature resolution	1°C, or better
10	Data storage	100 groups
11	Weight	38kg
12	Size	550 mm500mm580mm
13	Power supply	AC220V, 50Hz
14	Working environment	Room temperature to 45°C, humidity<85%

Picture of Dielectric Breakdown Voltage Portable Oil Tester

IEC 156 Dielectric Breakdown Voltage Portable Oil Tester
