ASTM D2419 Sand Equivalent Value Test Apparatus for Soils and Fine Aggregate

ASTM D2419 Sand Equivalent Value Test Apparatus for Soils and Fine Aggregate

    • ASTM D2419 Sand Equivalent Value Test Apparatus for Soils and Fine Aggregate
    • ASTM D2419 Sand Equivalent Value Test Apparatus for Soils and Fine Aggregate
    • ASTM D2419 Sand Equivalent Value Test Apparatus for Soils and Fine Aggregate
    • ASTM D2419 Sand Equivalent Value Test Apparatus for Soils and Fine Aggregate
    • ASTM D2419 Sand Equivalent Value Test Apparatus for Soils and Fine Aggregate
    • ASTM D2419 Sand Equivalent Value Test Apparatus for Soils and Fine Aggregate

    Detail produk:

    Tempat asal: CINA
    Nama merek: AI
    Sertifikasi: ISO
    Nomor model: Fase

    Syarat-syarat pembayaran & pengiriman:

    Kuantitas min Order: 1 buah
    Harga: Bisa dinegosiasikan
    Kemasan rincian: Kasus Kayu Lapis
    Waktu pengiriman: 10 hari
    Syarat-syarat pembayaran: T/T, Western Union
    Menyediakan kemampuan: 1000 pcs/bulan
    Hubungi sekarang
    Detil Deskripsi produk
    Standar uji: ASTM D2419 Siklus berosilasi: (180±2) kali/menit
    Amplitudo silinder: 203mm±1,0mm Kekuatan Dinilai: 130w
    Berat: 20kg Catu Daya: AC (220 ± 5%) V, 50Hz
    Ukuran: 564mm×320mm×360mm Jaminan: 1 tahun

    ASTM D2419 Fine Aggregate Sand Equivalent TesterASTM D2419 Sand Equivalent Value Test Apparatus for Soils and Fine Aggregate



    Summary
    This sand equivalent test instrument is designed and made as per T 0334 Sand Equivalent Test for Fine Aggregate in JTJ 058-2000 Specification and Test Methods of Aggregate for Highway Engineering. It is used to determine the cohesive soil content or impurity content in fine aggregates. The sand equivalent is expressed by SE. The maximum particle diameter shall be less than 4.75mm (The diameter of the sieve is 5mm)

    I. Main technical features
    1. Double-barrelled design. It can do the parallel oscillation automatically for two samples at a time. The working efficiency is high.
    2. Desktop structure. The oscillating frequency and time are both displayed on a LED screen. It can complete a periodic oscillation after sample is loaded.

    II.Specifications:
    1 Oscillating cycle (180±2) times/min
    2 Amplitude of cylinder 203mm±1.0mm
    3 Power supply AC(220±10%)V,50Hz
    4 Rated power 130 W
    5 Dimension of test cylinder Inner diameter is 32mm±0.25mm. Length is 420mm
    6 Flushing pipe OD is 6mm±0.5 mm, ID is 4mm±0.2mm
    7 Ambient temperature ≤35℃
    8 Relative humidity ≤85%
    9 Net weight 20kg
    10 Dimension 564mm×320mm×360mm
    11 Weight of piston 1kg±5g



    III.Accessories

    No. Item Unit Qty
    1 Spare belt(Bonding after burn at both ends to soften by user self) Piece 1
    2 Flushing pipe assembly

    Water absorbing skin cavity and

    flushing pipe

    		 Set 1
    Latex tube (Ф7, about 1 meter) Piece 2
    Infusion tube spring clips Piece 1
    3 Power line (250V 6A) Piece 1
    4 2A fuse (Ф5 × 20) Piece 3
    5 Funnel Piece 1
    6 Test tube (With a rubber stopper) Set 4
    7 Counterweight piston Set 1
    8 Steel ruler (500mm, precision 1mm) Piece 1
    9 Siphon pipe bending Piece 1
    10 Mercury thermometer (0 ~ 50 ℃, scale division is1 ℃) Piece 1
