Automatic Fraass Method Breaking Point Tester with Water Bath

Automatic Fraass Method Breaking Point Tester with Water Bath

    • Automatic Fraass Method Breaking Point Tester with Water Bath
    • Automatic Fraass Method Breaking Point Tester with Water Bath
    • Automatic Fraass Method Breaking Point Tester with Water Bath
    • Automatic Fraass Method Breaking Point Tester with Water Bath
    • Automatic Fraass Method Breaking Point Tester with Water Bath

    Detail produk:

    Tempat asal: CINA
    Nama merek: AI
    Sertifikasi: ISO
    Nomor model: BPT

    Syarat-syarat pembayaran & pengiriman:

    Kuantitas min Order: 1 buah
    Harga: Bisa dinegosiasikan
    Kemasan rincian: Kasus Kayu Lapis
    Waktu pengiriman: 10 hari
    Syarat-syarat pembayaran: T/T, Western Union
    Menyediakan kemampuan: 1000 pcs/bulan
    Hubungi sekarang
    Detil Deskripsi produk
    Metode pengujian: Metode Fras Rentang pengukuran suhu: -30℃～25℃
    Unit kerja: 3 pcs Irisan baja: 41mm×20mm×0,15mm
    Konsumsi daya: 2050W Catu Daya: AC (220 ± 5%) V, 50Hz
    Ukuran: 500mm×400mm×570mm Jaminan: 1 tahun

    Automatic Fraass Method Breaking Point Tester

    Automatic Fraass Method Breaking Point Tester with Water Bath

    Summary
    This breaking point tester is used to determine the temperature which a bitumen tends to break rather to flow when cooled and stressed as per standards GB/T 4510 and JTG E20-2011. It can do three tests at the same time in the same environment and calculate the average value. The cooling rate is controlled by computer.

    I. Main technical features
    The frass method breaking point test apparatus is controlled by micro computer. The cooling rate is controlled automatically. It automatically timing to bend samples. The test data is shown on the colored LCD and outputted by built-in printer.


    II.Specifications:

    1 Power supply AC(220±10%)V,50Hz
    2 Refrigeration mode Low temperature circulatory bath
    3 Cooling rate (1±0.5)℃/min
    4 Temperature measuring range -30℃～25℃
    5 Temperature measuring error ±0.5℃
    6 Steel slice 41mm×20mm×0.15mm
    7 Test samples It can determine 3 samples at the same time.
    8 Ambient temperature Room temp. ～+30℃
    9 Relative humidity ≤85%
    10 Power consumption 450W(breaking point tester)+ 1600W(low temperature circulatory bath)
    11 Overall dimension 500mm×400mm×570mm(breaking point tester)

    Note: We can customize the breaking point tester with measuring range:-40℃～25℃



    III.Accessories



    No. Name Unit Qty Memo
    1 Automatic Breaking Point Tester Set 1
    2 CWB-15 Low Temperature Cyclic Thermostatic Water Bath Set 1
    3 Stainless steel sample piece Piece 6
    4 Rubber pipe(Ф10×1 meter) Piece 2
    5 Insulated sponge pipe(Ф15×1 meter) Piece 2
    6 Operation manual Piece 1
    7 Low temperature cyclic thermostatic water bath usage Piece 1
