ASTM D1665 Engler Specific Viscometer Viscosity Tester with 2 Working Units

ASTM D1665 Engler Specific Viscometer Viscosity Tester with 2 Working Units

    • ASTM D1665 Engler Specific Viscometer Viscosity Tester with 2 Working Units
    • ASTM D1665 Engler Specific Viscometer Viscosity Tester with 2 Working Units
    • ASTM D1665 Engler Specific Viscometer Viscosity Tester with 2 Working Units
    • ASTM D1665 Engler Specific Viscometer Viscosity Tester with 2 Working Units
    • ASTM D1665 Engler Specific Viscometer Viscosity Tester with 2 Working Units

    Detail produk:

    Tempat asal: CINA
    Nama merek: AI
    Sertifikasi: ISO
    Nomor model: EV-II

    Syarat-syarat pembayaran & pengiriman:

    Kuantitas min Order: 1 buah
    Harga: Bisa dinegosiasikan
    Kemasan rincian: Kasus Kayu Lapis
    Waktu pengiriman: 10 hari
    Syarat-syarat pembayaran: T/T, Western Union
    Menyediakan kemampuan: 1000 pcs/bulan
    Hubungi sekarang
    Detil Deskripsi produk
    Standar uji: ASTM D1665 Catu Daya: AC (220±10%) V, 50Hz.
    Nilai air standar: (51 ± 1) s Kisaran Suhu: (0~100)℃
    Labu ukur: (200±0,2)ml Ukuran: 430mm×410mm×620mm
    Tujuan: tentukan laju waktu (detik) aliran cairan keluar dari viskometer Engler

    ASTM D1665 Engler Specific ViscometerASTM D1665 Engler Specific Viscometer Viscosity Tester with 2 Working Units

    Summary
    This engler viscometer is designed and made as per national standard GB/T266 Petroleum Products- Determination of Engler Viscosity, T0622 Bitumen Engler Viscosity Determination(Engler viscometer method) in national industrial standard JTG E20-2011 Standard Test Methods of Bitumen and Bituminous Mixtures for Highway Engineering and Shanghai enterprise standard Q/YXYY11 WNE-1 Engler Viscometer.
    It is suitable to determine the rate of time(seconds) of liquid flow out from Engler viscometer and time(seconds) of distilled water flow out at 20℃ under certain temperature and cubage. This rate is the Engler viscosity. Unit is Engler degree.

    I. Main technical features
    1. The engler viscosity tester adopts desktop, all-in-one and double inner crucible structure. Both of inner and outer crucibles adopt stainless materials. Inner crucible has been specially processed. The smooth finish corresponds with the test requirements.
    2. The flow out time of engler viscosity meter adopts digital display. Can do parallel determination for 2 samples at the same time. Easy to use and efficiency is high.
    3. The temperature controller adopts digital display temperature controller with P,I,D position regulatory function. Easy to set the parameters and temperature controlling precision is high.

    II. Main technical specifications
    1 Power supply AC(220±10%)V, 50Hz
    2 Standard water value (51±1)s
    3 Temperature range (0~100)℃
    4 Temperature control accuracy ±0.1℃
    5 Engler viscosity thermometer Correspond with GB/T 514
    6 Specification of measuring flask (200±0.2) ml
    7 Inner crucible Stainless steel material
    8 Timing Max 999.9s
    9 Timing mode LED electronic timing
    10 Heating power 700W
    11 Ambient temperature (-10~+40)℃
    12 Relative humidity ≤85%
    13 Dimension 430mm×410mm×620mm
    14 Maximum power consumption 800W

    IV.Package list
    No. Name Unit Qty Memo
    1



    Engler Viscometer

    		 Set 1
    2



    Temperature sensor

    		 Piece 1 Installed in the instrument
    3 Receiving flask (100ml) Piece 2
    4



    Engler thermometer (0 ~ 50) ℃, scale division is 0.5 ℃

    		 Piece 1
    5



    Engler thermometer (0～100) ℃, scale division is 0.1 ℃

    		 Piece 1
    6 Wooden stopper of viscometer Piece 2
    7 Fuse 10A(φ5×20) Piece 2
    8 Stopping ring for thermometer(1#) Piece 2
    9 Operating Manual Piece 1
