Name: Core Winding Test Equipment For Specimen Of Diameter φ 5 - 11mm
Brand: Advanced Instruments Co.,Ltd
SKU: AIC22056
Availability: InStock

Rumah Produk peralatan pengujian kabel

Core Winding Test Equipment For Specimen Of Diameter φ 5 - 11mm

Detail produk:

Tempat asal:	CINA
Nama merek:	AI
Sertifikasi:	ISO
Nomor model:	AIC22056

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1 SET Alat Uji Gulungan Inti
Harga:	Bisa dinegosiasikan
Kemasan rincian:	Kasus Kayu Lapis
Waktu pengiriman:	25 hari
Syarat-syarat pembayaran:	Western Union, T/T, L/C
Menyediakan kemampuan:	50 set per bulan

Hubungi sekarang

Detil Deskripsi produk

Aplikasi:	Komposit serat karbon	Kecepatan belitan:	3RPM
Diameter roda berliku:	φ275 ~ 605mm, total 13 ukuran	Kecepatan penyesuaian traksi sheave atas dan bawah:	150mm / mnt
Kisaran spesimen:	φ 5 ~ 11mm	Dimensi keseluruhan:	1600×730× 1810mm (L×W×T)
Catu Daya:	AC 220V 50/60HZ	Warna:	Putih

Product description:

Carbon fiber composite core winding test equipment is suitable for the winding property test of fiber reinforced polymer matrix composite core for overhead electrical conductors cables, fiber reinforced resin matrix composite core soft type aluminum wires.

It is composed by a chassis, the mechanical transmission part,the control part, the winding wheel, a protective cover, assembly of the damping device, the guide tubes and other components.

Standard:

• GB/T 29324.32-2012

Technical parameters:

• Winding speed: 3 r/min

• Winding wheel diameter: φ275 ~ 605mm, 13 sizes in total

• Upper and down adjusting speed of traction sheave: 150mm / min;

• Specimen range: φ 5 ~ 11mm;

• Removable acrylic shields, good transparency, high strength

Specifications:

• Overall dimensions: 1600×730× 1810mm (L×W× H)

• Power supply: 220V/50HZ
