HV Resonance Test System for GIS, Power cable and Generator Insulation Testing

Detail produk:

Tempat asal:	CINA
Nama merek:	AI
Sertifikasi:	ISO
Nomor model:	RTS

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1 set
Harga:	Bisa dinegosiasikan
Kemasan rincian:	Kasus Kayu Lapis
Waktu pengiriman:	15 hari
Syarat-syarat pembayaran:	T/T, Western Union, L/C
Menyediakan kemampuan:	100 set per bulan

Hubungi sekarang

Detil Deskripsi produk

Catu Daya:	380V±10%, tiga fase 50Hz/60Hz	Keluaran Tegangan Maks:	0~1000kV
Kapasitas Keluaran Maks:	0~6400KVA	Rentang Frekuensi Uji:	30~300Hz
Jaminan:	1 tahun	kata kunci:	Sistem uji resonansi HV

HV Resonance Test System

Name: HV Resonance Test System for GIS, Power cable and Generator Insulation Testing
Brand: Advanced Instruments Co.,Ltd
SKU: RTS
Availability: InStock

Introduction

HV Resonance Test System is applied to testing the insulation ability of insulation materials in power equipment. The frequency of test voltage is adjustable which would lead to series resonance in testing circuit. Both the conductors connected in test circuit in series and the capacitors connected in test circuit in parallel are also adjustable. That makes the resonance test system is widely applied in GIS, Power cable and generator insulation testing.

Technial specifications

1	Max voltage output	0~1000KV
2	Max output Capacity	0~6400KVA
3	Test frequency range	30~300HZ
4	Frequency setting resolution	0.1HZ
5	Test voltage waveform	sine wave,waveform deviation factor : ≤1%
6	Power supply	380V±10%, three-phase 50Hz/60Hz
7	Environment condition	Temperature: 0~50℃
8	Humidity	≤ 80%RH

Photo of HV Resonance Test System

HV Resonance Test System for GIS, Power cable and Generator Insulation Testing
