Name: LED Display IEC60851-3 Elongation Test Instrument for Copper Wires
Brand: Advanced Instruments Co.,Ltd
SKU: AISC-5
Availability: InStock

Rumah Produk peralatan pengujian kabel

LED Display IEC60851-3 Elongation Test Instrument for Copper Wires

Detail produk:

Tempat asal:	CINA
Nama merek:	AI
Sertifikasi:	ISO
Nomor model:	AISC-5

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1 SET Instrumen Uji Pemanjangan IEC60851-3
Harga:	Bisa dinegosiasikan
Kemasan rincian:	Satu kotak Kayu Lapis untuk Instrumen Uji Pemanjangan IEC60851-3
Waktu pengiriman:	90 hari
Syarat-syarat pembayaran:	Western Union, T/T, L/C
Menyediakan kemampuan:	10 set/bulan

Hubungi sekarang

Detil Deskripsi produk

Standar uji:	GB/T4074.3-2008,IEC60851-3	Fungsi:	uji perpanjangan (daktilitas) kabel tembaga
Objek uji:	kabel tembaga ditutupi dengan enamel φ0.018-φ3.000mm	Mulai jarak antara dua klem:	200±0,5mm
Kecepatan peregangan sampel:	300±60mm/menit	Rentang pengujian perpanjangan maksimum:	≥80%
Daya Input:	AC220V ± 10% 50Hz	Konsumsi daya:	≤200w
Dimensi keseluruhan:	640×420×410mm	Berat:	45kg

Performance Characteristics

Executive standard: GB/T4074.3-2008,IEC60851-3; Inspection standard: JB/T4279.3-2008
This Elongation Test Instrument is used to test elongation (ductility) of copper wires covered with φ0.018-φ3.000mm enamel, silk or other insulation materials and other metal wires with tensile strength ≤2000N;
This Elongation Test Instrument adopts SCM control for fast operation and strong anti-interference capacity;
Clamps are designed according to characteristics of various wires to prevent samples from breaking at clamp jaws, easy to load samples and, after samples are compressed, enamel can be automatically broken;
While sample is broken, movable clamp would automatically stop moving, with error between displayed and actual elongation value less than 1%;

Major Technical Parameters

Start distance between two clamps	200±0.5mm
Stretching speed of sample	300±60mm/min
Maximum elongation testing range ( displacement distance of movable clamp)	≥80% (≥160mm)
Display of elongation	LED display, display accuracy of 0.1%
Input power	AC220V±10% 50Hz
Power consumption	≤200W
Overall dimensions	L×W×H 640×420×410mm
Weight	45kg

LED Display IEC60851-3 Elongation Test Instrument for Copper Wires
