IEC60851-3 Bending Test Tool for Flat Wires with Low Price and Good Warranty

IEC60851-3 Bending Test Tool for Flat Wires with Low Price and Good Warranty

    • IEC60851-3 Bending Test Tool for Flat Wires with Low Price and Good Warranty
    • IEC60851-3 Bending Test Tool for Flat Wires with Low Price and Good Warranty
    • IEC60851-3 Bending Test Tool for Flat Wires with Low Price and Good Warranty
    • IEC60851-3 Bending Test Tool for Flat Wires with Low Price and Good Warranty

    Detail produk:

    Tempat asal: CINA
    Nama merek: AI
    Sertifikasi: ISO
    Nomor model: AIBXW-16

    Syarat-syarat pembayaran & pengiriman:

    Kuantitas min Order: 1 SET Alat Uji Bending
    Harga: Bisa dinegosiasikan
    Kemasan rincian: Satu kotak Kayu Lapis untuk Alat Uji Bending IEC60851-3
    Waktu pengiriman: 90 hari
    Syarat-syarat pembayaran: Western Union, T/T, L/C
    Menyediakan kemampuan: 10 set/bulan
    Hubungi sekarang
    Detil Deskripsi produk
    Standar uji: GB/T4074.3-2008,IEC60851-3 Diameter flensa: φ260mm atau φ370mm
    Panjang menekuk dan memutar lengan: 350 atau 400mm Warna: Biru
    Menampilkan: dipimpin Sudut putaran lengan yang berputar: >180°
    Jumlah batang Pagoda: 3 Diameter batang pagoda: φ4~φ60mm
    Jumlah batang Bulat: 88 jenis Diameter batang bulat: φ4~φ80mm

    Performance Characteristics
    1.Executive standard: GB/T4074.3-2008,IEC60851-3;
    2.This     Bending Test Tool is applicable to the bending test of various enameled flat wires, paper wrapped flat wires, glass fiber wrapped flat wires, film wrapped wires and other electromagnetic wires with a wide edge of less than or equal to 16mm, as well as the corresponding copper and aluminum flat wires.

    Major Technical Parameters

    Bending host machine 1# machine 2# machine
    Diameter of flange φ260mm φ370mm
    Length of bending and rotating arm 350mm 400mm
    Rotation angle of rotating arm >180°
    Number of test bar and diameter range Pagoda bar: 3, φ4~φ60mm
    Round bar (standard times of diameter) 88 types, φ4~φ80mm


    Note: For round bars with non-standard diameter, they can be customized according to users' needs
