Name: IEC60851-3 Jerk Test Apparatus with Jerking Speed above 3m/s for Wires
Brand: Advanced Instruments Co.,Ltd
SKU: AIJLD-10
Availability: InStock

Rumah Produk peralatan pengujian kabel

IEC60851-3 Jerk Test Apparatus with Jerking Speed above 3m/s for Wires

Detail produk:

Tempat asal:	CINA
Nama merek:	AI
Sertifikasi:	ISO
Nomor model:	AIJLD-10

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1 SET Alat Uji Jerk
Harga:	Bisa dinegosiasikan
Kemasan rincian:	Satu kotak Kayu Lapis untuk Alat Tes Jerk
Waktu pengiriman:	90 hari
Syarat-syarat pembayaran:	Western Union, T/T, L/C
Menyediakan kemampuan:	10 set/bulan

Hubungi sekarang

Detil Deskripsi produk

Standar uji:	IEC60851-3	Kecepatan menyentak:	≥3m/dtk
Mulai jarak antara dua klem:	250±1mm	Jarak bergerak maksimum:	125mm
Tekanan kerja:	0,4 ~ 0,8MPa	Catu Daya:	AC220V ± 10% 50Hz
Konsumsi daya:	<150w	Dimensi:	650×405×425mm
Berat:	55kg	Warna:	Biru

Performance Characteristics
1.Executive standard: GB/T4074.3-2008,IEC60851-3;
2.Inspection standard: JB/T4279.5-2008
3.This Jerk Test Apparatus is used to measure the film adhesion property of enameled round wires with nominal conductor diameter of 1.000mm and below;
4.Built-in small ultra-quiet air compressor would provide power supply and automatic constant pressure;
5.When the sample is pulled abruptly, it will not move or slip;

Technical Parameters

Jerking speed	≥3m/s
Start distance between two clamps	250±1mm
Maximum moving distance of movable clamp	125mm
Working pressure	0.4~0.8MPa
Input power	AC220V±10% 50Hz
Power consumption	<150W
Overall dimensions	L×W×H 650×405×425mm
Weight	55kg

IEC60851-3 Jerk Test Apparatus with Jerking Speed above 3m/s for Wires
